1. FACTORY ECU & MICROCONTROLLER INSTALLED ON THIS VEHICLEBENCH / BOOT / OBD VERIFIED
| Make & Model (Chassis) | Pontiac — All Brand Models (Direct ECU Label Lookup) |
|---|---|
| Engine & Power Spec | Read/Write PFLASH/ExtEEPROM/ExtFLASH, CheckSum |
| Engine Control Unit (ECU) | BOSCH ME9.6.1 |
| Internal Microcontroller (MCU) | MPC563/4 |
| Read / Write Connection Mode | Platform (Bench No-Open) |
| Supported Programmer Functions | Full PFLASH + DFLASH Backup Read/Write (1:1 ECU Cloning) + Auto Checksum Correction |
| Available Files in 800 TB Vault | Exact ECU Maps: 0 (.A2L/.KP/.OLS) | Family Maps: 0 | ROMs: 0 |
2. OFFICIAL BENCH / BOOT ECU CONNECTOR PINOUT DIAGRAM1 DIAGRAMS
OFFICIAL BENCH / BOOT ECU PINOUT DIAGRAM: BOSCH ME9.6.1 MPC563_4.png
