1. FACTORY ECU & MICROCONTROLLER INSTALLED ON THIS VEHICLEBENCH / BOOT / OBD VERIFIED
| Make & Model (Chassis) | Universal ECU Protocol — Universalnyy protokol Bosch MPC5xx / Delphi MTxx / Continental Easy-U |
|---|---|
| Engine & Power Spec | Direct Bench / Boot ECU Connector Pinout |
| Engine Control Unit (ECU) | BOSCH EDC16C3 MPC555/6 |
| Internal Microcontroller (MCU) | test |
| Read / Write Connection Mode | Platform / Locked Boot Unlock |
| Supported Programmer Functions | Full PFLASH + DFLASH Backup Read/Write (1:1 ECU Cloning) + Auto Checksum Correction |
| Available Files in 800 TB Vault | Exact ECU Maps: 1 (.A2L/.KP/.OLS) | Family Maps: 0 | ROMs: 8 |
2. OFFICIAL BENCH / BOOT ECU CONNECTOR PINOUT DIAGRAM1 DIAGRAMS
OFFICIAL BENCH / BOOT ECU PINOUT DIAGRAM: BOSCH EDC16C3 MPC555_6.png
