ECU Pinout MD1CP001 Bench / Boot / GPT Pinout — Wiring Diagram

Step-by-step bench connection diagram for ECU MD1CP001 (non-invasive Platform Bench & Boot Mode): T30/T15 power supply, twisted-pair CAN-H/CAN-L, and GPT0/GPT1 signal pinout.

OFFICIAL PINOUT DIAGRAM: BOSCH MD1CP001.png (Platform / Bench)194,273 bytes
BOSCH MD1CP001.png
STEP-BY-STEP BENCH CONNECTION PROCEDURE (HOWTO PROTOCOL)BENCH / BOOT
  1. Step 1 (Terminal 30 & Terminal 15 Power): Apply regulated bench power 13.5V — 13.8V to constant battery (T30), switched ignition (T15), and ground (GND) pins according to the harness color code above.
  2. Step 2 (CAN Bus & GPT0 / GPT1 Signals): Connect CAN-H & CAN-L, along with signal leads GPT0 (S1) & GPT1 (S2) to enter bench service mode without opening the ECU housing.
  3. Step 3 (Full PFLASH + DFLASH Backup Read): Before writing any calibration, read and archive a full backup of internal Program Flash (PFLASH) and Data Flash / EEPROM (DFLASH).
VEHICLES EQUIPPED WITH ECU MD1CP001 (13)VEHICLE COMPATIBILITY
MakeModel & EngineECU & MCUAction
Audi A7(C8) (2967 • 286) BOSCH MD1CP001 (SPC5777) Open Vehicle →
Mercedes-Benz C180W213 (300 3000 CDI OM642DE30LAR 204) BOSCH MD1CP001 (SPC5777) Open Vehicle →
Mercedes-Benz C180W222 (2996 OM656.DE29LA 340) BOSCH MD1CP001 (SPC5777) Open Vehicle →
Mercedes-Benz CLS(C257) (2925 OM642.855 286) BOSCH MD1CP001 (SPC5777) Open Vehicle →
Mercedes-Benz E(W213) (200 d OM654.920 150) BOSCH MD1CP001 (SPC5777) Open Vehicle →
Mercedes-Benz E(W213) (220 d OM654.920 194) BOSCH MD1CP001 (SPC5777) Open Vehicle →
Mercedes-Benz E(W213) (220 d 4MATIC OM654.920 194) BOSCH MD1CP001 (SPC5777) Open Vehicle →
Mercedes-Benz EW212 (1991 654.916 160) BOSCH MD1CP001 (SPC5777) Open Vehicle →
Mercedes-Benz GLC(X253) (1991 OM654DE30LAR 211) BOSCH MD1CP001 (SPC5777) Open Vehicle →
Mercedes-Benz GLE(W167) (2996 OM656.DE29LA 340) BOSCH MD1CP001 (SPC5777) Open Vehicle →
Mercedes-Benz S(W222) (2927 OM656.929 286) BOSCH MD1CP001 (SPC5777) Open Vehicle →
Audi All Brand Models (Direct ECU Label Lookup) (Read/Write EEPROM/FLASH, CheckSum) BOSCH MD1CP001 (SPC5777) Open Vehicle →
Mercedes-Benz All Brand Models (Direct ECU Label Lookup) (Read/Write EEPROM/FLASH, CheckSum) BOSCH MD1CP001 (SPC5777) Open Vehicle →
